R Core Tube AMP Transformer High Conversion Efficiency For Industrial Automation Equipment

Name: R Core Tube AMP Transformer High Conversion Efficiency For Industrial Automation Equipment
Brand: Tube AMP Transformer
Price: 1 USD

China R Core Tube AMP Transformer High Conversion Efficiency For Industrial Automation Equipment wholesale

Brand Name : Tube AMP Transformer

Model Number : 15Vx2+9Vx1

Certification : ROHS

Place of Origin : China

MOQ : Negotiable

Payment Terms : Paypal, T/T, Western Union

Supply Ability : 1000pcs/month

Packaging Details : Standard box

Function : Transformer

Coil Structure : Toroidal

Power : 30W

Input voltage : 115V/230V

Output Voltage : 15Vx2+9Vx1

Price : Negotiable

Contact Now

Tube AMP Transformer Brass skin 115V/230V 30W R-Core Transformer for Audio Amplifier DAC 15Vx2+9Vx1

Other moder for Audio DAC Tube Amplifier:

Model	Power	Voltage (input)	Voltage (output)	Application(Size)
R3	30W	115V-230V	Double 12V + Double 9V	78×71×H43(mm)
	30W	115V-230V	Double 18V + Double 9V	80×68×40(mm)
	30W	115V-230V	9V×3+6.3V+240V	80×68×40(mm)
	30W	115V-230V	Double 15V + Double 6V	80×68×40(mm)
	30W	115V-230V	Double 18V	75×69×H41(mm)
	30W	115V-230V	Double 18V + Double 12V	79×68×39(mm)
	30W	115V-230V	Double 15V + Single 9V	75×69×H41(mm)
	30W	115V-230V	Double 24V	80×68×40(mm)
	30W	115V-230V	Double 15V	79×68×40(mm)
	30W	115V-230V	Double 15V+ Double 9V	80×68×40(mm)
	30W	115V-230V	Double 9V	79×68×40(mm)
	380W	115V-230V	Double 30V(5.9A)+ Double12V(1A)	158×128 ×68(mm)
	30W	115V-230V	Double 32V	79×68×39(mm)
	30W	115V-230V	Double 12V	79×68×39(mm)
	30W	115V-230V	9V x 4	79×68×39(mm)
E1	120W	115V-230V	30V×2+15V×2	115mm×42mm
R2	200W	115V-230V	20V(4.75A)×2+12V(0.4A)×2	135×110×60(mm)
	200W	115V-230V	24V(3.7A)×2+12V(0.8A)×2	135×110×60(mm
	200W	115V-230V	26V(3.4A)×2+15V(0.8A)×2	135×110×60(mm
	200W	115V-230V	30V×2+15V×2	135×110×60(mm
	200W	115V-230V	32V×2+15V×2	135×110×60(mm
	200W	115V-230V	36V(2.45A)×2+15V(0.8A)×2	135×110×60(mm
	200W	115V-230V	40V(2.2A)×2+15V(0.8A)×2	135×110×60(mm
	200W	115V-230V	28V×2+15V×2	135×110×60(mm

We also can make other transformer:

Features:
1.Small volume,
2.Low noise,
3.Less calorific power,
4.High conversion efficiency

APPLICATIONS:
1.Industrial automation equipment
2.Instrumentation, petrochemical industry
3.Medical and health
4.Agricultural production
5.Mechanical processing
6.Scientific research
7.War industry
8.Household electrical appliances

R Core Tube AMP Transformer High Conversion Efficiency For Industrial Automation Equipment

The dimension

Output Power P2/VA	Out Diameter(mm)	Heigh(mm)	Heigh of assembly(mm)
8	55	25	30
15	63	33	37
30	70	33	38
50	80	38	45
80	97	35	39
120	95	43	47
160	110	45	50
225	110	50	55
300	110	57	62
500	135	63	67
625	145	78	83
750	150	80	85
1000	160	80	85
1500	200	75	80

Product material

Name	Specification	Features
Cold rolling orientation quality ferrosilicon	0.27mm or 0.30mm	Low iron loss High magnetic
Lacquer clad round copper wire	QZ-150,QZ-180	Anaerobic copper High strength Low loss
BOPET thin film	0.05mm-0.08mm	Reduction: 150°c in 30minutes
PV soft copper wire	Technical drawing	450V/750V

R Core Tube AMP Transformer High Conversion Efficiency For Industrial Automation Equipment
