Metal Material Tube AMP Transformer Enclosure Box For E / R Transformer

Product Categories
Youda Audio Co. Limited
Contact Now

Metal Material Tube AMP Transformer Enclosure Box For E / R Transformer

  • 1
  • 2

Brand Name : Tube AMP Transformer

Model Number : 80×88×H100mm

Certification : Rhos

Place of Origin : China

MOQ : Negotiable

Payment Terms : Paypal, T/T, Western Union

Supply Ability : 1000pcs/month

Packaging Details : Standard box

Type : For E , R transformer

Application : Audio amplifier

Outside Dimension : 80×88×H100mm

Inside Dimension : 80×87×H98mm

Thickness : 2mm

Material : Metal

Price : Negotiable

Contact Now

Tube AMP Transformer AMP Transformer Triode Cover Enclosure Case Box 80×88×H100mm

Type: For E , R transformer

Application: Audio amplifier

Outside Dimension: 80×88×H100mm

Inside Dimension:80×87×H98mm

Thickness:2mm

Material:Metal

Transformers for Audio DAC Tube Amplifier:

Model Power Voltage (input) Voltage (output) Application(Size)
R3 30W 115V-230V Double 12V + Double 9V 78×71×H43(mm)
30W 115V-230V Double 18V + Double 9V 80×68×40(mm)
30W 115V-230V 9V×3+6.3V+240V 80×68×40(mm)
30W 115V-230V Double 15V + Double 6V 80×68×40(mm)
30W 115V-230V Double 18V 75×69×H41(mm)
30W 115V-230V Double 18V + Double 12V 79×68×39(mm)
30W 115V-230V Double 15V + Single 9V 75×69×H41(mm)
30W 115V-230V Double 24V 80×68×40(mm)
30W 115V-230V Double 15V 79×68×40(mm)
30W 115V-230V Double 15V+ Double 9V 80×68×40(mm)
30W 115V-230V Double 9V 79×68×40(mm)
380W 115V-230V Double 30V(5.9A)+ Double12V(1A) 158×128 ×68(mm)
30W 115V-230V Double 32V 79×68×39(mm)
30W 115V-230V Double 12V 79×68×39(mm)
30W 115V-230V 9V x 4 79×68×39(mm)
E1 120W 115V-230V 30V×2+15V×2 115mm×42mm
R2 200W 115V-230V 20V(4.75A)×2+12V(0.4A)×2 135×110×60(mm)
200W 115V-230V 24V(3.7A)×2+12V(0.8A)×2 135×110×60(mm
200W 115V-230V 26V(3.4A)×2+15V(0.8A)×2 135×110×60(mm
200W 115V-230V 30V×2+15V×2 135×110×60(mm
200W 115V-230V 32V×2+15V×2 135×110×60(mm
200W 115V-230V 36V(2.45A)×2+15V(0.8A)×2 135×110×60(mm
200W 115V-230V 40V(2.2A)×2+15V(0.8A)×2 135×110×60(mm
200W 115V-230V 28V×2+15V×2 135×110×60(mm

Model Power Voltage (input) Voltage (output) Application(Size)
R5 50W 115V-230V Double 12V + Double 9V 78×71×H43(mm)
50W 115V-230V Double 18V + Double 9V 80×68×40(mm)
50W 115V-230V Double 15V + Double 6V 80×68×40(mm
50W 115V-230V Double 18V 75×69×H41(mm)
50W 115V-230V Double 18V + Double 12V 79×68×39(mm)
50W 115V-230V Double 15V + Single 9V 80×68×40(mm)
50W 115V-230V Double 15V+ Double 9V 80×68×40(mm)

Metal Material Tube AMP Transformer Enclosure Box For E / R Transformer

Metal Material Tube AMP Transformer Enclosure Box For E / R Transformer

Metal Material Tube AMP Transformer Enclosure Box For E / R Transformer
